Multi-function Cable Route Tracer for Precise Underground Cable Locator

Name: Multi-function Cable Route Tracer for Precise Underground Cable Locator
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: Xhgx507
Price: 1,050.00 USD
Availability: InStock

Ürün Ayrıntıları:

Menşe yeri:	XI'AN ShanXi
Marka adı:	XZH TEST
Sertifika:	ISO
Model numarası:	Xhgx507

Ayrıntılı Bilgiler

Menşe yeri:

XI'AN ShanXi

Marka adı:

XZH TEST

Sertifika:

ISO

Model numarası:

Xhgx507

Vurgulamak:

High Light

Vurgulamak:

Multi-function Cable Route Tracer

Competitive Price Cable Fault Locator

Acoustic-Magnetic Synchronization Underground Cable Locator

Trading Information

Min sipariş miktarı:

1 takım

Ambalaj bilgileri:

Ahşap ambalaj

Teslim süresi:

5-8 iş günü

Ödeme koşulları:

T/T

Yetenek temini:

3000 birim/yıl

Ürün Tanımı

XHGX507

Product Overview

The Cable Route Tracer is an essential tool for accurately locating and tracing underground cables and wiring routes.

XHGX507 underground cable pipe locator is mainly used for cable fault location, cable identification, cable path and depth measurement. It can complete tasks that could only be accomplished by a few sets of instruments in the past.

Features

The large-screen LCD displays the signal strength, and the bar, arrows and voice prompts make it easy for the operator to judge the underground position of the cable and the fault point. One person can do it all.

All-digital design, clear large-screen LCD graphic display and reliable positioning

Portable and lightweight, easy to carry

Built-in rechargeable battery

Built-in ohmmeter to measure cable loop resistance

Can be used to detect insulation faults up to 2MΩ to ground

With backlight function to adapt to night operation

Built-in ohmmeter to measure cable loop resistance

Display cable depth and current

Main components

This cable pipe locator is mainly composed of transmitter and receiver, with accessories of two clamps, one A-frame and necessary connection wires.

Multi-function Cable Route Tracer for Precise Underground Cable Locator 0

Multi-function Cable Route Tracer for Precise Underground Cable Locator 1
